0548190519
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / USB, DVI, HDMI Connectors
Description
Conn Mini USB 2.0 Type B F 5 POS 0.8mm Solder RA Thru-Hole 5 Terminal 1 Port USB OTG Tray
PDF
/
Buying Options
Total Price: USD $1.85
Unit Price: USD $1.848
≥1 USD $1.848
≥10 USD $1.57784
≥100 USD $1.303174
≥500 USD $1.028826
≥1000 USD $0.960238
Inventory: 19700
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Through Hole, Right Angle
Mounting Feature Horizontal
Insulation Material GLASS FILLED POLYAMIDE
Shell Material POLYETHYLENE
Mounting Option 1 DETENT
Mounting Option 2 LOCKING
Shell/Shielding Material Copper Alloy
Technical
Operating Temperature -20°C~85°C
Packaging Tray
Series 54819
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type USB - mini B
Gender Receptacle
Voltage - Rated 30V
Additional Feature POLARIZED
Subcategory Telecom and Datacom Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 1A
Shielding Shielded
Insulation Color Black
Shell Finish TIN OVER NICKEL
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.303 inch
Number Of PCB Rows 2
Number of Contacts 5
PCB Contact Pattern STAGGERED
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Empty Shell NO
Contact Style USB, SER B SQ
Polarization Key POLARIZED HOUSING
Number of Ports 1
Mating Cycles 5000
Specifications USB 2.0 OTG
Dimensions
Plating Thickness 30μin
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
