0483950003
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / USB, DVI, HDMI Connectors
Description
CONN RCP USB3.0 TYPEA 9POS TH RA
PDF
/
Inventory: 1555
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Specifications USB 3.0 (USB 3.1 Gen 1, Superspeed)
Mating Cycles 5000
Withdrawl Force-Min .4726 N
Insertion Force-Max 35.00576 N
Number of Ports 1
Contact Style USB, SER A FLAT
PCB Contact Pattern STAGGERED
Number of Contacts 9
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Number of Conductors ONE
Insulation Color Blue
Terminal Pitch 2.0066mm
Shielding Shielded
Current Rating (Amps) 0.25A 1.8A
Subcategory Telecom and Datacom Connectors
Voltage - Rated 30VAC/DC
Gender Receptacle
Connector Type USB-A (USB TYPE-A)
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series 48395
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Physical
Shell/Shielding Material Steel, Stainless
Mounting Option 1 LOCKING
Insulation Material THERMOPLASTIC
Mounting Feature Horizontal, Mid Mount, Reverse
Mounting Type Board Edge, Cutout; Through Hole, Right Angle
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 17 Weeks
