0471510112
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / USB, DVI, HDMI Connectors
Description
Conn HDMI HDR 19 POS 0.5mm Solder RA SMD 19 Terminal 1 Port Tray
PDF
/
Inventory: 8336
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold, Tin
Mount Horizontal, Surface Mount
Mounting Type Surface Mount, Right Angle; Through Hole
Mounting Feature Flange, Horizontal
Housing Material Thermoplastic
Shell/Shielding Material Copper Alloy
Technical
Operating Temperature -20°C~85°C
Packaging Tray
Series 47151
JESD-609 Code e6
Feature Detent Lock
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type HDMI
Number of Rows 2
Gender Receptacle
Voltage - Rated 40VDC
HTS Code 8536.69.40.30
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.5ADC
Pitch 500μm
Orientation Right Angle
Shielding Shielded
Depth 12.15mm
Reach Compliance Code unknown
Current Rating 500mA
Insulation Color Natural
Shell Finish NICKEL
Contact Finish Gold
Number of Contacts 19
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Empty Shell NO
Number of Ports 1
Max Voltage Rating (DC) 40V
Dimensions
Length 15mm
Compliance
RoHS Status ROHS3 Compliant
