EZA-EGCA50AV
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Circuit Protection / TVS - Varistors, MOVs
Description
VARISTOR 0805
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.5808
≥1 USD $0.5808
≥10 USD $0.50952
≥100 USD $0.478368
≥500 USD $0.390456
≥1000 USD $0.362666
≥3000 USD $0.308651
Inventory: 4172
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 2mm
Technical
Varistor Voltage 100V
Direction Bidirectional
Clamping Voltage 100V
Max Voltage Rating (DC) 15V
Output Current 100mA
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Number of Circuits 4
Leakage Current 100nA
Number of Channels 1
Configuration SINGLE
Polarity UNIDIRECTIONAL
Working Voltage 15V
Number of Elements 1
Operating Supply Voltage 15V
Case Code (Imperial) 0805
Case Code (Metric) 2012
Pin Count 10
Time@Peak Reflow Temperature-Max (s) 10
Depth 1.25mm
Peak Reflow Temperature (Cel) 260
Terminal Form FLAT
Terminal Position DUAL
Technology AVALANCHE
Voltage - Rated DC 15V
Subcategory Transient Suppressors
Capacitance 250FF
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2010
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 10
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount, MLCV
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
