ERZ-E08F751 image
Favorite
ERZ-E08F751 image
Favorite
RoHS
RoHS RoHS compliant
Package Disc 11.5mm
Category Circuit Protection / TVS - Varistors, MOVs
Description Varistors ERZ-E 8mm 750V T&R ZNR Surge Absorber
PDF
/
Inventory: 7237
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 9.7mm
Diameter 11.5mm

Technical

Clamping Current 25A
Varistor Voltage 750V
Varistor Voltage (Typ) 750V
Varistor Voltage (Min) 675V
Energy 100J
Varistor Voltage (Max) 825V
Capacitance @ Frequency 130pF @ 1kHz
Max Surge Current 3.5kA
Clamping Voltage 1.24kV
Max Voltage Rating (DC) 615V
Max Voltage Rating (AC) 460V
Number of Circuits 1
Voltage 615V
Lead Pitch 7.5mm
Voltage - Rated AC 460V
Resistor Type VARISTOR
Voltage - Rated DC 615V
Capacitance 130pF
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ZNR?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Physical

Package / Case Disc 11.5mm
Mounting Type Through Hole
Mount Radial, Through Hole

Supply Chain

Factory Lead Time 10 Weeks
