ERZ-E08A681CS image
Favorite
ERZ-E08A681CS image
Favorite
RoHS
RoHS RoHS compliant
Package Disc 11.5mm
Category Circuit Protection / TVS - Varistors, MOVs
Description VARISTOR 680V 3.5KA DISC 11.5MM
PDF
/
Inventory: 1999
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 9mm
Diameter 11.5mm

Technical

Clamping Current 25A
Varistor Voltage 680V
Varistor Voltage (Typ) 680V
Varistor Voltage (Min) 612V
Energy 92J
Varistor Voltage (Max) 748V
Capacitance @ Frequency 130pF @ 1kHz
Max Surge Current 3.5kA
Clamping Voltage 1.12kV
Max Voltage Rating (DC) 560V
Max Voltage Rating (AC) 420V
Number of Circuits 1
Voltage 560V
Lead Pitch 7.5mm
Voltage - Rated AC 420V
Resistor Type VARISTOR
Voltage - Rated DC 560V
Capacitance 130pF
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ZNR?
Packaging Bulk
Operating Temperature -40°C~85°C TA

Physical

Package / Case Disc 11.5mm
Mounting Type Through Hole
Mount Radial, Through Hole

Supply Chain

Factory Lead Time 10 Weeks
