ERZ-E05A391CS
RoHS
RoHS compliant
RoHS compliantPackage Disc 7mm
Category Circuit Protection / TVS - Varistors, MOVs
Description
VARISTOR 390V 1.2KA DISC 7MM
PDF
/
Inventory: 7243
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.4mm
Diameter 7mm
Technical
Clamping Current 10A
Varistor Voltage 351V
Varistor Voltage (Typ) 390V
Varistor Voltage (Min) 351V
Energy 26J
Varistor Voltage (Max) 429V
Capacitance @ Frequency 130pF @ 1kHz
Max Surge Current 1.2kA
Clamping Voltage 650V
Max Voltage Rating (DC) 320V
Max Voltage Rating (AC) 250V
Number of Circuits 1
Lead Pitch 5mm
Voltage - Rated AC 250V
Resistor Type VARISTOR
Voltage - Rated DC 320V
Capacitance 130pF
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ZNR?
Packaging Bulk
Operating Temperature -40°C~85°C TA
Physical
Package / Case Disc 7mm
Mounting Type Through Hole
Mount Radial, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
