V751HC32
RoHS
RoHS compliant
RoHS compliantPackage Disc 32mm, Formed Tabs
Category Circuit Protection / TVS - Varistors, MOVs
Description
VARISTOR 1.2KV 25KA DISC 32MM
PDF
/
Buying Options
Total Price: USD $15.41
Unit Price: USD $15.412133
≥1 USD $15.412133
≥200 USD $5.964505
≥500 USD $5.755754
≥1000 USD $5.652035
Inventory: 3990
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Bolt, Surface Mount
Mounting Type Bolt Mount
Package / Case Disc 32mm, Formed Tabs
Terminal Shape FLAT
Technical
Operating Temperature -55°C~85°C TA
Packaging Bulk
Published 2014
Series HC
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Through Hole
ECCN Code EAR99
Terminal Finish Tin (Sn)
HTS Code 8533.40.40.00
Capacitance 800pF
Subcategory Non-linear Resistors
Voltage - Rated DC 970V
Technology METAL OXIDE FILM
Resistor Type VARISTOR
Reach Compliance Code unknown
Voltage - Rated AC 750V
Rated Power Dissipation (P) 2W
Number of Circuits 1
Max Voltage Rating (AC) 750V
Terminal Placement RADIAL
Max Voltage Rating (DC) 970V
Clamping Voltage 2.05kV
Max Surge Current 25kA
Capacitance @ Frequency 800pF @ 1MHz
Varistor Voltage (Max) 1.32kV
Energy 700J
Varistor Voltage (Min) 1.08kV
Maximum AC Volts 750V
Varistor Voltage 1.2kV
Dimensions
Diameter 32mm
Compliance
RoHS Status ROHS3 Compliant
