V250LU20AP
RoHS
RoHS compliant
RoHS compliantPackage Disc 14mm
Category Circuit Protection / TVS - Varistors, MOVs
Description
VARISTOR 390V 4.5KA DISC 14MM
PDF
/
Inventory: 9992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Radial, Through Hole
Mounting Type Through Hole
Package / Case Disc 14mm
Terminal Shape WIRE
Technical
Operating Temperature -55°C~85°C TA
Packaging Tape & Reel (TR)
Published 2009
Series LU
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Terminal Finish Tin (Sn)
HTS Code 8533.40.40.00
Capacitance 500pF
Subcategory Non-linear Resistors
Voltage - Rated DC 330V
Packing Method TR
Technology METAL OXIDE FILM
Resistor Type VARISTOR
Reach Compliance Code unknown
Current Rating 4.5kA
Voltage - Rated AC 250V
Rated Power Dissipation (P) 0.6W
Max Output Current 4.5kA
Number of Circuits 1
Max Voltage Rating (AC) 250V
Max Voltage Rating (DC) 330V
Clamping Voltage 650V
Max Surge Current 4.5kA
Capacitance @ Frequency 500pF @ 1MHz
Varistor Voltage (Max) 429V
Energy 72J
Varistor Voltage (Min) 351V
Varistor Voltage 390V
Dimensions
Diameter 14mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
