V20P14P
RoHS
RoHS compliant
RoHS compliantPackage Disc 20mm
Category Circuit Protection / TVS - Varistors, MOVs
Description
Varistors 14V 20mm Phenolic UltraMOV
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.758792
≥1 USD $0.758792
≥10 USD $0.715845
≥100 USD $0.675327
≥500 USD $0.637101
≥1000 USD $0.601039
Inventory: 1070
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Technical
Circuit RMS Voltage-Max 20V
Varistor Voltage 22V
Varistor Voltage (Typ) 22V
Varistor Voltage (Min) 19.8V
Energy 80J
Varistor Voltage (Max) 24.2V
Capacitance @ Frequency 22200pF @ 1MHz
Max Surge Current 8kA
Clamping Voltage 43V
Max Voltage Rating (DC) 18V
Max Voltage Rating (AC) 14V
Number of Circuits 1
Lead Pitch 8.5mm
Voltage - Rated AC 14V
Current Rating 1mA
Reach Compliance Code unknown
Resistor Type VARISTOR
Technology METAL OXIDE FILM
Voltage - Rated DC 18V
Subcategory Non-linear Resistors
Capacitance 18nF
HTS Code 8533.40.40.00
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LV UltraMOV?
Published 2014
Packaging Bulk
Operating Temperature -40°C~125°C TA
Physical
Package / Case Disc 20mm
Mounting Type Through Hole
Mount Radial, Through Hole
Supply Chain
Factory Lead Time 18 Weeks
