TPA220
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 220V 150A DO15
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.6424
≥1 USD $0.6424
≥10 USD $0.49192
≥100 USD $0.408144
Inventory: 483
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AC, DO-15, Axial
Number of Pins 2
Technical
Packaging Tape & Box (TB)
Series TPA, TRISIL?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Capacitance 25pF
Subcategory Silicon Surge Protectors
Voltage - Rated DC 220V
Terminal Form WIRE
Base Part Number TPA
Pin Count 2
Operating Supply Voltage 198V
Number of Elements 1
Polarity Bidirectional
Element Configuration Single
Case Connection ISOLATED
Max Reverse Leakage Current 2μA
Peak Pulse Current 150A
Reverse Standoff Voltage 198V
Max Surge Current 50A
Peak Pulse Power 1.7W
Test Current 5μA
Breakdown Voltage 220V
Max Repetitive Reverse Voltage (Vrrm) 220V
Hold Current 150mA
Max Breakdown Voltage 220V
Trigger Device Type SILICON SURGE PROTECTOR
ESD Protection Yes
Voltage - Breakover 293V
Min Breakdown Voltage 220V
Dimensions
Diameter 3.53mm
Height 6.75mm
Length 6.75mm
Width 3.53mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
