TPA180RL
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 180V 150A DO204AC
PDF
/
Inventory: 1589
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - Breakover 240V
Current - Hold (Ih) 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 150mA
Breakdown Voltage 180V
Peak Pulse Power 1.7W
Max Surge Current 5mA
Peak Pulse Current 150A
Current - Peak Pulse (10/1000μs) 50A
Case Connection ISOLATED
Configuration SINGLE
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 162V
Qualification Status Not Qualified
JESD-30 Code O-PALF-W2
Pin Count 2
Base Part Number TPA
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
Subcategory Silicon Surge Protectors
Capacitance 25pF
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series TPA, TRISIL?
Packaging Tape & Reel (TR)
Physical
Surface Mount NO
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
