TPA120
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Thyristors
Description
TRISIL TELECOM PROTECTION DO-15
PDF
/
Inventory: 8124
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length 6.75mm
Diameter 3.53mm
Technical
Voltage - Breakover 160V
Current - Hold (Ih) 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 150mA
Breakdown Voltage 120V
Peak Pulse Power 1.7W
Max Surge Current 50A
Peak Pulse Current 150A
Case Connection ISOLATED
Configuration SINGLE
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 108V
Qualification Status Not Qualified
Pin Count 2
Base Part Number TPA
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
Voltage - Rated DC 120V
Subcategory Silicon Surge Protectors
Capacitance 30pF
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series TPA, TRISIL?
Packaging Tape & Box (TB)
Physical
Number of Pins 2
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
