THDT6511DRL

STMicroelectronics
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Circuit Protection / TVS - Thyristors
Description THYRISTOR 40A 8SOIC
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 8025
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8

Technical

Packaging Tape & Reel (TR)
Series LCP
JESD-609 Code e3/e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Termination SMD/SMT
Terminal Finish MATTE TIN/NICKEL PALLADIUM GOLD
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Capacitance 500pF
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Reach Compliance Code unknown
Base Part Number THDT651
Pin Count 8
Qualification Status Not Qualified
Operating Supply Voltage 63V
Number of Elements 1
Polarity Bidirectional
Number of Channels 2
Peak Pulse Current 40A
Max Surge Current 1mA
Breakdown Voltage 65V
Max Repetitive Reverse Voltage (Vrrm) 65V
Telecom IC Type SURGE PROTECTION CIRCUIT
Hold Current 150mA
Voltage - Breakover 68V

Dimensions

Length 4.9mm
Width 3.9mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
