SMTPA62
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
TRISIL 62V BIDIRECT SMB
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5368
≥1 USD $0.5368
≥10 USD $0.45672
≥100 USD $0.317504
≥500 USD $0.247914
≥1000 USD $0.201502
Inventory: 1422
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.95mm
Length 4.6mm
Height 2.45mm
Technical
Min Breakdown Voltage 62V
Voltage - Breakover 82V
Trigger Device Type SILICON SURGE PROTECTOR
Max Breakdown Voltage 62V
Hold Current 150mA
Max Repetitive Reverse Voltage (Vrrm) 62V
Breakdown Voltage 62V
Test Current 5μA
Direction Bidirectional
Max Surge Current 50A
Reverse Standoff Voltage 56V
Peak Pulse Current 150A
Clamping Voltage 82V
Max Reverse Leakage Current 2μA
Element Configuration Single
Number of Elements 1
Operating Supply Voltage 56V
Pin Count 2
Base Part Number SMTPA
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Voltage - Rated DC 62V
Subcategory Silicon Surge Protectors
Capacitance 40pF
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SMP, TRISIL?
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 17 Weeks
