SMP50-200
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 200V 150A DO214AC
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7656
≥1 USD $0.7656
≥10 USD $0.66704
≥100 USD $0.461912
≥500 USD $0.385986
≥1000 USD $0.328504
≥3000 USD $0.292574
Inventory: 1369
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 2.9mm
Length 4.6mm
Height 2.45mm
Technical
Voltage - Breakover 267V
Trigger Device Type SILICON SURGE PROTECTOR
Max Breakdown Voltage 200V
Hold Current 150mA
Max Repetitive Reverse Voltage (Vrrm) 200V
Breakdown Voltage 200V
Direction Bidirectional
Max Surge Current 50A
Reverse Standoff Voltage 180V
Peak Pulse Current 150A
Max Reverse Leakage Current 5μA
Element Configuration Single
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 180V
Pin Count 2
Base Part Number SMP50
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Voltage - Rated DC 200V
Subcategory Silicon Surge Protectors
Capacitance 25pF
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SMP, TRISIL?
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 17 Weeks
