SMP2300SCMC

STMicroelectronics
RoHS
RoHS RoHS compliant
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description THYRISTOR 230V 400A SMB
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.424626
≥1 USD $0.424626
≥10 USD $0.404404
≥100 USD $0.385739
Inventory: 2437
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 3.95mm
Length 4.6mm
Height 2.45mm

Technical

Min Breakdown Voltage 230V
Voltage - On State 3V
Voltage - Breakover 260V
Hold Current 150mA
Telecom IC Type SURGE PROTECTION CIRCUIT
RMS Current (Irms) 5μA
Direction Bidirectional
Reverse Standoff Voltage 190V
Peak Pulse Current 400A
Max Reverse Leakage Current 5μA
Current - Peak Pulse (10/1000μs) 100A
Element Configuration Single
Number of Elements 1
Base Part Number SMP2300
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form C BEND
Terminal Position DUAL
Capacitance 45pF
Min Operating Temperature -40°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series SMP-0SCMC, TRISIL?
Packaging Tape & Reel (TR)

Physical

Weight 179.991122mg
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 7 months ago)
