SMP1300SCMC

STMicroelectronics
RoHS
RoHS RoHS compliant
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description THYRISTOR 130V 400A SMB
PDF
/
Inventory: 3393
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 7 months ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Weight 179.991122mg

Technical

Packaging Tape & Reel (TR)
Series SMP-0SCMC, TRISIL?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Capacitance 75pF
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number SMP1300
Number of Elements 1
Element Configuration Single
Current - Peak Pulse (10/1000μs) 100A
Max Reverse Leakage Current 5μA
Peak Pulse Current 400A
Reverse Standoff Voltage 120V
Direction Bidirectional
RMS Current (Irms) 5μA
Telecom IC Type SURGE PROTECTION CIRCUIT
Hold Current 150mA
Voltage - Breakover 160V
Voltage - On State 3V
Min Breakdown Voltage 130V

Dimensions

Height 2.45mm
Length 4.6mm
Width 3.95mm

Compliance

RoHS Status ROHS3 Compliant
