SMP100MC-140
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
TVS Diodes - Transient Voltage Suppressors TELECOM EQUIPMENT PROTECTION TRISIL
PDF
/
Buying Options
Total Price: USD $2.65
Unit Price: USD $2.650312
≥1 USD $2.650312
≥10 USD $2.325891
≥100 USD $2.132285
≥500 USD $6.10375
≥1000 USD $5.90045
Inventory: 21
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Series SMP, TRISIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Capacitance 60pF
Voltage - Rated DC 140V
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number SMP100
Pin Count 2
Operating Supply Voltage 126V
Number of Elements 1
Polarity Bidirectional
Current - Peak Pulse (10/1000μs) 100A
Peak Pulse Current 300A
Reverse Standoff Voltage 126V
Max Surge Current 500A
Breakdown Voltage 140V
Max Repetitive Reverse Voltage (Vrrm) 140V
Telecom IC Type SURGE PROTECTION CIRCUIT
Hold Current 150mA
Max Breakdown Voltage 140V
Current - Hold (Ih) 150mA
Voltage - Breakover 175V
Dimensions
Height 2.45mm
Length 4.6mm
Width 3.95mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
