SMP100LC-160
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
TRISIL 100A 160V BIDIRECT SMB
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.6688
≥1 USD $0.6688
≥10 USD $0.58168
≥100 USD $0.402776
≥500 USD $0.33653
≥1000 USD $0.286405
Inventory: 2536
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.95mm
Length 4.6mm
Height 2.45mm
Technical
Min Breakdown Voltage 160V
Voltage - Breakover 200V
Current - Hold (Ih) 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Max Breakdown Voltage 160V
Hold Current 150mA
Max Repetitive Reverse Voltage (Vrrm) 160V
Breakdown Voltage 160V
Max Surge Current 100A
Reverse Standoff Voltage 144V
Peak Pulse Current 400A
Configuration SINGLE
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 144V
Pin Count 2
Base Part Number SMP100
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Voltage - Rated DC 160V
Subcategory DIACs
Capacitance 65pF
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SMP, TRISIL?
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
