LCP02-150M-TR

STMicroelectronics
RoHS
RoHS RoHS compliant
Package PowerSO-10 Exposed Bottom Pad
Category Circuit Protection / TVS - Thyristors
Description TVS Diodes / ESD Suppressors Programmable TVS
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.14795
≥1 USD $2.14795
≥10 USD $1.7632
≥100 USD $1.7081
≥500 USD $1.653
≥1000 USD $1.5979
Inventory: 4203
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 7.5mm
Length 9.4mm
Height Seated (Max) 3.75mm

Technical

Hold Current 150mA
Telecom IC Type SURGE PROTECTION CIRCUIT
Max Surge Current 5μA
Peak Pulse Current 250A
Current - Peak Pulse (10/1000μs) 100A
Number of Channels 2
Temperature Grade OTHER
Number of Elements 1
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Pin Count 10
Base Part Number LCP02
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code not_compliant
Number of Functions 1
Peak Reflow Temperature (Cel) 250
Terminal Form GULL WING
Terminal Position DUAL
Capacitance 150pF
Terminal Finish Matte Tin (Sn)
Termination SMD/SMT
Number of Terminations 10
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Series LCP
Packaging Tape & Reel (TR)

Physical

Number of Pins 10
Surface Mount YES
Package / Case PowerSO-10 Exposed Bottom Pad
Mounting Type Surface Mount
