NP3500SBT3G
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
DO-214AA SMB 1 Surface Mount SILICON SURGE PROTECTOR TVS Thyristor 400V 2.2A 44pF 150C
PDF
/
Buying Options
Total Price: USD $2.32
Unit Price: USD $2.32085
≥1 USD $2.32085
≥10 USD $1.90475
≥100 USD $1.8449
≥500 USD $1.786
≥1000 USD $1.72615
Inventory: 1212
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Voltage - On State 4V
Voltage - Breakover 400V
Current - Hold (Ih) 150mA
Voltage - Off State 320V
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 250mA
Peak Pulse Current 80A
Configuration SINGLE
Number of Elements 1
Pin Count 2
Time@Peak Reflow Temperature-Max (s) 40
Current Rating 2.2A
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Subcategory Silicon Surge Protectors
Capacitance 44pF
Additional Feature UL RECOGNIZED
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Tin (Sn)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
