NP1800SBMCT3G
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
DO-214AA SMB 1 Surface Mount SILICON SURGE PROTECTOR TVS Thyristor 170V 80A 29pF 150C
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.373798
≥1 USD $0.373798
≥10 USD $0.352639
≥100 USD $0.332684
≥500 USD $0.313853
≥1000 USD $0.296086
Inventory: 1221
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2010
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Capacitance 29pF
Terminal Position DUAL
Terminal Form C BEND
Pin Count 2
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 80A
Peak Pulse Current 250A
Max Repetitive Reverse Voltage (Vrrm) 170V
Hold Current 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Non-Repetitive Pk On-state Cur 30 A
Voltage - Breakover 220V
Voltage - On State 4V
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
