NP1800GBRLG

ON Semiconductor
RoHS
/
Package DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Thyristors
Description THYRISTOR 170V 80A DO204AC
PDF
/
Inventory: 5775
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Voltage - On State 4V
Voltage - Breakover 220V
Voltage - Off State 170V
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 150mA
Peak Pulse Current 80A
Current - Peak Pulse (10/1000μs) 80A
Case Connection ISOLATED
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PALF-W2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
Subcategory Silicon Surge Protectors
Capacitance 100pF
Additional Feature UL RECOGNIZED
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2007
Packaging Tape & Reel (TR)

Physical

Surface Mount NO
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
