NP1100SCMCT3G
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 90V 400A DO214AA
PDF
/
Inventory: 5746
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Voltage - On State 4V
Voltage - Breakover 130V
Non-Repetitive Pk On-state Cur 30 A
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 150mA
Max Repetitive Reverse Voltage (Vrrm) 90V
Peak Pulse Current 400A
Current - Peak Pulse (10/1000μs) 100A
Configuration SINGLE
Number of Elements 1
Pin Count 2
Terminal Form C BEND
Terminal Position DUAL
Subcategory Silicon Surge Protectors
Capacitance 33pF
Additional Feature UL RECOGNIZED
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2009
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
