MMT05B310T3
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
DO-214AA SMB 1 Surface Mount SILICON SURGE PROTECTOR TVS Thyristor 365V 50A 75pF 125C
PDF
/
Buying Options
Total Price: USD $2.39
Unit Price: USD $2.38925
≥1 USD $2.38925
≥10 USD $1.95985
≥100 USD $1.89905
≥500 USD $1.8373
≥1000 USD $1.7765
Inventory: 1109
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Capacitance 75pF
Subcategory DIACs
Voltage - Rated DC 270V
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 2
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 50A
Peak Pulse Current 150A
Hold Current 340mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 270V
Current - Hold (Ih) 150mA
Voltage - Breakover 365V
Voltage - On State 3V
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
