SMTBJ170A
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
TVS Diodes / ESD Suppressors SiBOD DO214AA-CR
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.632818
≥1 USD $0.632818
≥200 USD $0.245512
≥500 USD $0.236322
≥1000 USD $0.232383
Inventory: 4632
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 4.57mm
Technical
Current - Peak Pulse (8/20μs) 150A
Voltage - On State 2V
Voltage - Breakover 215V
Current - Hold (Ih) 150mA
Non-Repetitive Pk On-state Cur 30 A
Trigger Device Type SILICON SURGE PROTECTOR
Breakdown Voltage 180V
Max Surge Current 50A
Configuration SINGLE
Polarity Bidirectional
Working Voltage 170V
Number of Elements 1
Qualification Status Not Qualified
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form C BEND
Terminal Position DUAL
Capacitance 35pF Max
Additional Feature UL RECOGNIZED
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Series SIDACtor?
Published 2005
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Surface Mount YES
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
