SMTBJ050B
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
TVS Diodes - Transient Voltage Suppressors SiBOD SURFMT DO214AA-CR
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.557983
≥1 USD $0.557983
≥200 USD $0.216629
≥500 USD $0.208751
≥1000 USD $0.204812
Inventory: 7004
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2002
Series SIDACtor?
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Additional Feature UL RECOGNIZED
Capacitance 85pF Max
Subcategory Silicon Surge Protectors
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Qualification Status Not Qualified
Operating Temperature (Min) -40°C
Operating Supply Voltage 50V
Number of Elements 1
Polarity Bidirectional
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 100A
Max Surge Current 100A
Breakdown Voltage 60V
Hold Current 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Non-Repetitive Pk On-state Cur 30 A
Voltage - Breakover 80V
Voltage - On State 2V
Current - Peak Pulse (8/20μs) 250A
Compliance
RoHS Status Non-RoHS Compliant
