P6002AD
RoHS
/
Package TO-220-3 No Tab
Category Circuit Protection / TVS - Thyristors
Description
SIDAC SYM 2CHP 550V 1000A TO220
PDF
/
Inventory: 1542
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Voltage - On State 5.5V
Voltage - Breakover 700V
Voltage - Off State 550V
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 50mA
Peak Pulse Current 1kA
Current - Peak Pulse (10/1000μs) 250A
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-PSIP-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 60
Current Rating 2.2A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 245
Terminal Position SINGLE
Subcategory Silicon Surge Protectors
Capacitance 200pF
HTS Code 8541.30.00.80
Additional Feature UL RECOGNIZED
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series SIDACtor?
Published 2005
Packaging Bulk
Physical
Surface Mount NO
Package / Case TO-220-3 No Tab
Mounting Type Through Hole
