P6002ACMC
RoHS
/
Package TO-220-3 No Tab
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 275V/550V 400A TO220-3
PDF
/
Inventory: 6761
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Voltage - On State 4V
Voltage - Breakover 350V 700V
Non-Repetitive Pk On-state Cur 50 A
Voltage - Off State 275V 550V
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 150mA
Peak Pulse Current 400A
Current - Peak Pulse (10/1000μs) 100A
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-PSIP-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 2.2A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Capacitance 25pF 45pF
HTS Code 8541.30.00.80
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series SIDACtor?
Published 2005
Packaging Bulk
Physical
Surface Mount NO
Package / Case TO-220-3 No Tab
Mounting Type Through Hole
