P4802ABL
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 No Tab
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 220V/440V 250A TO220-3
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5377
≥1 USD $0.5377
≥10 USD $0.4408
≥100 USD $0.4275
≥500 USD $0.41325
≥1000 USD $0.39995
Inventory: 1154
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 No Tab
Number of Pins 3
Weight 6.000006g
Technical
Packaging Bulk
Published 2005
Series SIDACtor?
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Capacitance 50pF 85pF
Subcategory Silicon Surge Protectors
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Current - Peak Pulse (10/1000μs) 80A
Peak Pulse Current 250A
Hold Current 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 220V 440V
Voltage - Breakover 300V 600V
Voltage - On State 4V
Dimensions
Length 10.4mm
Width 9.53mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
