P3602ABL60
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 No Tab
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 170V/340V 250A TO220-3
PDF
/
Buying Options
Total Price: USD $2.08
Unit Price: USD $2.075695
≥1 USD $2.075695
≥200 USD $0.803495
≥500 USD $0.775924
≥1000 USD $0.761482
Inventory: 7012
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Mounting Type Through Hole
Package / Case TO-220-3 No Tab
Surface Mount NO
Number of Pins 3
Technical
Packaging Bulk
Published 2011
Series SIDACtor?
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish MATTE TIN
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Capacitance 50pF 90pF
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Current - Peak Pulse (10/1000μs) 80A
Peak Pulse Current 250A
Hold Current 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 170V 340V
Voltage - Breakover 220V 440V
Voltage - On State 4V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
