P3602AB
RoHS
/
Package TO-220-3 No Tab
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 170V/340V 250A TO220-3
PDF
/
Inventory: 1645
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Voltage - On State 4V
Repetitive Peak Reverse Voltage 160V
Voltage - Breakover 220V 440V
Non-Repetitive Pk On-state Cur 30 A
Voltage - Off State 170V 340V
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 150mA
Peak Pulse Current 250A
Current - Peak Pulse (10/1000μs) 80A
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-PSIP-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 2.2A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Subcategory Silicon Surge Protectors
Capacitance 50pF 90pF
HTS Code 8541.30.00.80
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series SIDACtor?
Published 2004
Packaging Bulk
Physical
Surface Mount NO
Package / Case TO-220-3 No Tab
Mounting Type Through Hole
