P3403UALTP
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Gull Wing
Category Circuit Protection / TVS - Thyristors
Description
SIDAC SYM 3CHP 300V 150A MS013
PDF
/
Buying Options
Total Price: USD $1.98
Unit Price: USD $1.977227
≥1 USD $1.977227
≥200 USD $0.765421
≥500 USD $0.739163
≥1000 USD $0.724721
Inventory: 2933
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mounting Type Surface Mount
Package / Case 6-SMD, Gull Wing
Surface Mount YES
Technical
Packaging Tube
Published 2004
Series SIDACtor?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Capacitance 45pF 65pF
Subcategory Silicon Surge Protectors
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 6
JESD-30 Code R-PDSO-G6
Qualification Status Not Qualified
Number of Elements 3
Current - Peak Pulse (10/1000μs) 45A
Peak Pulse Current 150A
Hold Current 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 300V
Non-Repetitive Pk On-state Cur 20 A
Voltage - Breakover 400V
Voltage - On State 8V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
