P3100SD
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
SIDAC BIDIR 275V 1000A DO-214AA
PDF
/
Inventory: 4201
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Surface Mount YES
Technical
Packaging Bulk
Published 2004
Series SIDACtor?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Lead (Sn/Pb)
Capacitance 70pF
Subcategory Silicon Surge Protectors
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
JESD-30 Code R-PDSO-C2
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Number of Elements 1
Configuration SINGLE
Case Connection MAIN TERMINAL 2
Current - Peak Pulse (10/1000μs) 200A
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 275V
Non-Repetitive Pk On-state Cur 50 A
Current - Hold (Ih) 50mA
Voltage - Breakover 350V
Repetitive Peak Reverse Voltage 275V
Voltage - On State 4V
Holding Current-Max 50mA
Current - Peak Pulse (8/20μs) 1kA
Compliance
RoHS Status Non-RoHS Compliant
