P3100SARP
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 275V 150A DO214AA
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.152
≥1 USD $0.152
≥10 USD $0.1254
≥100 USD $0.1216
≥500 USD $0.1178
≥1000 USD $0.11305
Inventory: 47001
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
Published 2012
Series SIDACtor?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Lead (Sn/Pb)
Capacitance 35pF
Subcategory Silicon Surge Protectors
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-C2
Qualification Status Not Qualified
Operating Temperature (Min) -40°C
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 45A
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 275V
Non-Repetitive Pk On-state Cur 20 A
Current - Hold (Ih) 150mA
Voltage - Breakover 350V
Repetitive Peak Reverse Voltage 275V
Voltage - On State 4V
Current - Peak Pulse (8/20μs) 150A
Compliance
RoHS Status Non-RoHS Compliant
