P2702AB
RoHS
/
Package TO-220-3 No Tab
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 120V/240V 250A TO220-3
PDF
/
Inventory: 4696
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-220-3 No Tab
Surface Mount NO
Technical
Packaging Bulk
Published 2004
Series SIDACtor?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
HTS Code 8541.30.00.80
Capacitance 60pF 105pF
Subcategory Silicon Surge Protectors
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-PSIP-T3
Qualification Status Not Qualified
Number of Elements 2
Current - Peak Pulse (10/1000μs) 80A
Peak Pulse Current 250A
Hold Current 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 120V 240V
Non-Repetitive Pk On-state Cur 30 A
Voltage - Breakover 160V 320V
Voltage - On State 4V
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
