P2302SA image
Favorite
P2302SA image
Favorite
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description THYRISTOR 190V 150A DO214AA
PDF
/
Inventory: 2168
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Technical

Voltage - On State 8V
Voltage - Breakover 260V
Voltage - Off State 190V
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 120mA
Peak Pulse Current 150A
Current - Peak Pulse (10/1000μs) 45A
Configuration SINGLE
Number of Elements 2
Qualification Status Not Qualified
Pin Count 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 2.2A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form C BEND
Terminal Position DUAL
Capacitance 25pF
HTS Code 8541.30.00.80
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series TwinChip?
Published 2006
Packaging Tape & Reel (TR)

Physical

Surface Mount YES
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
