P2300ECMCLRP1
RoHS
RoHS compliant
RoHS compliantPackage TO-226-2, TO-92-2 (TO-226AC)
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 190V 400A TO226-2
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.777237
≥1 USD $0.777237
≥200 USD $0.301967
≥500 USD $0.291464
≥1000 USD $0.286212
Inventory: 9138
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mounting Type Through Hole
Package / Case TO-226-2, TO-92-2 (TO-226AC)
Surface Mount NO
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2004
Series SIDACtor?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Capacitance 50pF
Subcategory Silicon Surge Protectors
Voltage - Rated DC 190V
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 3
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 100A
Peak Pulse Current 400A
Hold Current 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 190V
Non-Repetitive Pk On-state Cur 30 A
Voltage - Breakover 260V
Voltage - On State 4V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
