P2300EB
RoHS
/
Package TO-226-2, TO-92-2 (TO-226AC)
Category Circuit Protection / TVS - Thyristors
Description
SIDACTOR BIDIR 190V 250A TO-92
PDF
/
Buying Options
Total Price: USD $10.25
Unit Price: USD $10.2543
≥1 USD $10.2543
≥10 USD $8.41415
≥100 USD $8.151
≥500 USD $7.88785
≥1000 USD $7.62565
Inventory: 9503
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Voltage - On State 4V
Voltage - Breakover 260V
Non-Repetitive Pk On-state Cur 30 A
Voltage - Off State 190V
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 150mA
Peak Pulse Current 250A
Current - Peak Pulse (10/1000μs) 80A
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PBCY-T2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 2.2A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Voltage - Rated DC 190V
Subcategory Silicon Surge Protectors
Capacitance 50pF
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series SIDACtor?
Published 2004
Packaging Bulk
Physical
Surface Mount NO
Package / Case TO-226-2, TO-92-2 (TO-226AC)
Mounting Type Through Hole
