P1304UCMCRP
RoHS
/
Package 6-SMD, Gull Wing
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 120V/240V 400A 6SMD GW
PDF
/
Inventory: 7229
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 6-SMD, Gull Wing
Technical
Packaging Tape & Reel (TR)
Published 2006
Series SIDACtor?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Capacitance 35pF 60pF
Current Rating 2.2A
Number of Elements 4
Current - Peak Pulse (10/1000μs) 100A
Peak Pulse Current 400A
Hold Current 150mA
Voltage - Off State 120V 240V
Current - Hold (Ih) 150mA
Voltage - Breakover 160V 320V
Voltage - On State 8V
Current - Peak Pulse (8/20μs) 400A
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
