P1100SDLRP
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
SIDACTOR BI 90V 1000A DO214
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.4696
≥1 USD $1.4696
≥10 USD $1.2012
≥100 USD $0.934208
≥500 USD $0.791842
≥1000 USD $0.645031
Inventory: 1165
Minimum: 1
-
+
Technical Details
Technical
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Capacitance 115pF
Subcategory Silicon Surge Protectors
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 2
JESD-30 Code R-PDSO-C2
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 200A
Peak Pulse Current 1kA
Hold Current 50mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 90V
Voltage - Breakover 130V
Repetitive Peak Reverse Voltage 90V
Voltage - On State 4V
Series SIDACtor?
Published 2004
Packaging Tape & Reel (TR)
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Surface Mount YES
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
