P0644UCLTP
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Gull Wing
Category Circuit Protection / TVS - Thyristors
Description
SIDACTOR 4CHP 58/116V 400A MS013
PDF
/
Buying Options
Total Price: USD $2.84
Unit Price: USD $2.83849
≥1 USD $2.83849
≥200 USD $1.098897
≥500 USD $1.060823
≥1000 USD $1.04113
Inventory: 3500
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, Gull Wing
Number of Pins 6
Technical
Packaging Tube
Published 2011
Series SIDACtor?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Capacitance 90pF 155pF
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Terminal Pitch 3.505mm
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 6
Qualification Status Not Qualified
Number of Elements 4
Current - Peak Pulse (10/1000μs) 100A
Peak Pulse Current 400A
Telecom IC Type SURGE PROTECTION CIRCUIT
Hold Current 150mA
Voltage - Off State 58V 116V
Voltage - Breakover 77V 154V
Voltage - On State 4V
Dimensions
Length 9.195mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
