P0300SAMCLRP

Littelfuse Inc.
RoHS
RoHS RoHS compliant
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description SIDACTOR MC BI 25V 150A DO-214AA
PDF
/
Buying Options
Total Price: USD $0.06
Unit Price: USD $0.05605
≥1 USD $0.05605
≥10 USD $0.0456
≥100 USD $0.04465
≥500 USD $0.04275
≥1000 USD $0.0418
Inventory: 14132
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 3.95mm
Length 4.6mm
Height 2.45mm

Technical

Voltage - On State 4V
Voltage - Breakover 40V
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 50mA
Switching Voltage 40V
Max Repetitive Reverse Voltage (Vrrm) 25V
Peak Pulse Current 150A
Current - Peak Pulse (10/1000μs) 45A
Configuration SINGLE
Number of Elements 1
Pin Count 2
Current Rating 2.2A
Terminal Form C BEND
Terminal Position DUAL
Subcategory Silicon Surge Protectors
Capacitance 35pF
Additional Feature UL RECOGNIZED
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SIDACtor?
Published 2004
Packaging Tape & Reel (TR)

Physical

Weight 95.991485mg
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 18 Weeks
