P0080SARP
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
SIDACTOR BIDIR 6V 150A DO-214AA
PDF
/
Buying Options
Total Price: USD $0.12
Unit Price: USD $0.1216
≥1 USD $0.1216
≥10 USD $0.09975
≥100 USD $0.0969
≥500 USD $0.0931
≥1000 USD $0.09025
Inventory: 3092
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
Published 2004
Series SIDACtor?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Capacitance 150pF
Subcategory Silicon Surge Protectors
Voltage - Rated DC 6V
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
JESD-30 Code R-PDSO-C2
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 45A
Peak Pulse Current 150A
Hold Current 50mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 6V
Non-Repetitive Pk On-state Cur 20 A
Voltage - Breakover 25V
Repetitive Peak Reverse Voltage 6V
Voltage - On State 4V
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
