TISP4300M3LMFR-S
RoHS
RoHS compliant
RoHS compliantPackage TO-226-2, TO-92-2 (TO-226AC) (Formed Leads)
Category Circuit Protection / TVS - Thyristors
Description
Sidacs PROTECTOR - SINGLE BIDIRECTIONAL
PDF
/
Inventory: 4862
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-2, TO-92-2 (TO-226AC) (Formed Leads)
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Capacitance 55pF
Terminal Position BOTTOM
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Current Rating 5A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TISP4300
Pin Count 2
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 50A
Peak Pulse Current 220A
Max Repetitive Reverse Voltage (Vrrm) 230V
Hold Current 600mA
Trigger Device Type SILICON SURGE PROTECTOR
Current - Hold (Ih) 150mA
Voltage - Breakover 300V
Voltage - On State 3V
Compliance
RoHS Status ROHS3 Compliant
