TISP4125M3LMR-S
RoHS
RoHS compliant
RoHS compliantPackage TO-226-2, TO-92-2 (TO-226AC)
Category Circuit Protection / TVS - Thyristors
Description
Sidacs Single bidirectional protector
PDF
/
Inventory: 2004
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - On State 3V
Voltage - Breakover 125V
Current - Hold (Ih) 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 600mA
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Pulse Current 220A
Current - Peak Pulse (10/1000μs) 50A
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
Pin Count 2
Base Part Number TISP4125
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 5A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
Terminal Position BOTTOM
Capacitance 65pF
Additional Feature UL RECOGNIZED
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case TO-226-2, TO-92-2 (TO-226AC)
Mounting Type Through Hole
Mount Through Hole
