TISP4080M3BJR-S
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
Thyristor Surge Protection Devices 65V 32A 2-Pin SMB T/R
PDF
/
Buying Options
Total Price: USD $3.46
Unit Price: USD $3.46465
≥1 USD $3.46465
≥10 USD $2.8424
≥100 USD $2.75405
≥500 USD $2.66475
≥1000 USD $2.5764
Inventory: 31007
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - On State 3V
Voltage - Breakover 80V
Current - Hold (Ih) 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 350mA
Max Repetitive Reverse Voltage (Vrrm) 65V
Peak Pulse Current 220A
Current - Peak Pulse (10/1000μs) 50A
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
Pin Count 2
Base Part Number TISP4080
Time@Peak Reflow Temperature-Max (s) 40
Current Rating 5A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Capacitance 87pF
Additional Feature UL RECOGNIZED
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2005
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
