TISP3380F3DR
RoHS
/
Package 8-CSOIC (0.154, 3.90mm Width)
Category Circuit Protection / TVS - Thyristors
Description
SURGE SUPP 270V BIDIR 8-SOIC
PDF
/
Inventory: 1451
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-CSOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Technical
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Additional Feature UL RECOGNIZED
Capacitance 45pF
Subcategory Silicon Surge Protectors
Voltage - Rated DC 270V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 5A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TISP3380
Pin Count 8
Qualification Status Not Qualified
Number of Elements 2
Current - Peak Pulse (10/1000μs) 35A
Peak Pulse Current 120A
Hold Current 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 270V
Non-Repetitive Pk On-state Cur 4.3 A
Voltage - Breakover 380V
Voltage - On State 3V
Compliance
RoHS Status Non-RoHS Compliant
