TVS3300DRVR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 6-WDFN Exposed Pad
Category Circuit Protection / TVS - Mixed Technology
Description TVS MIXED TECHNOLOGY 40VC 6WSON
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.49192
≥100 USD $0.341968
≥500 USD $0.267027
≥1000 USD $0.217043
Inventory: 11983
Minimum: 1
-
+

Technical Details

Technical

Applications General Purpose
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Breakdown Voltage-Max 39V
Voltage - Clamping 40V
Breakdown Voltage-Min 34V
Rep Pk Reverse Voltage-Max 33V
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Number of Circuits 1
Polarity UNIDIRECTIONAL
Base Part Number TVS3300
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Technology Mixed Technology

Physical

Diode Element Material SILICON
Number of Pins 6
Surface Mount YES
Package / Case 6-WDFN Exposed Pad
Mounting Type Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Thickness 750μm
Width 2mm
Length 2mm
Height 800μm
